The wedge
Our power-infra scopes use the same Tier-1 components US developers already buy direct. The difference is integration and the production line. We assemble, factory-test, and ship as one delivery instead of five components on five purchase orders waiting on five lead times.
In the catalog
Sold standalone or as an integrated power package. Per-class spec sheets publish as each configuration is validated.
Switchboard sizing per AI deployment
A typical 60 MW AI data center needs 15–24 LV main switchboards depending on N/2N topology and rack-density mix. Exact equipment scope depends on redundancy, feeder architecture, and commissioning requirements. Public OEM timing varies by configuration; obtain a current quote for an exact comparison.
4000A LV switchboard
LV main switchboard at 4000A continuous, 480V three-phase. Fits the standard modular DC container at 60–80 kW/rack density. Type-tested per IEC 61439 TTA; UL 891 dual-cert path via NRTL listing for US installations. Breaker, contactor, protection, and power-monitoring functions integrated. Teraplex delivery window: 16 weeks; the July 2026 public OEM reference for listed LV switchboards spans 18–34 weeks.
Spec sheet →6300A LV switchboard · flagship
LV main switchboard at 6300A continuous, 480V three-phase, type-tested per IEC 61439 TTA with a UL 891 dual-cert path via NRTL listing. The natural single-unit fit for NVL72-class deployments at 120+ kW/rack. Public OEM timing at this amperage is configuration-specific; the Teraplex quoted delivery window is 16 weeks.
Spec sheet →MV switchgear
IEC 62271 with an IEEE C37 dual-cert path for US grid interconnection. 6 kV, 10 kV, 15 kV, 20 kV, and 35 kV classes. Relay-protection panels and grid-connection scope included as part of the substation package, not a separate procurement.
Spec sheet →Modular substations
Cast-resin dry-type transformers, 1–5 MVA typical for data center applications. Containerized for field deployment: substation, transformer, MV switch, and LV feed shipped as one factory-tested package. Other transformer ratios on request.
Spec sheet →Generator sets
Tier-1 OEM diesel gensets from 15 kVA to 3 MW with automatic transfer switches and paralleling controls for multi-genset configurations. Containerized for outdoor deployment. Diesel standard; bi-fuel and gas configurations available. Genset, ATS, and switchgear are integration-tested together before shipping.
Spec sheet →SCADA & integration
SCADA spanning power distribution, process control, and real-time metering. Modbus, SNMP, BACnet, and REST API for any DCIM or BMS integration. Industrial-grade controls panels sized to the substation, genset, and switchgear scope on the project.
Spec sheet →Lead-time tracker
Distribution transformers, MV switchgear, dry-type, gensets, ATS, UPS: what the wider market is quoting versus what we're quoting, refreshed every quarter. The data we use to triage your project schedule is the same data we publish.
Read the July 2026 tracker →Subscribe
Tell us your one-line, your need-by date, and your TAA or federal requirements. We come back within one to two US business days.
